Replacement

Adjustment

4 August 2009

TR-3-1

COVERS

3. REPLACEMENT AND ADJUSTMENT

3.1 COVERS

3.1.1 FRONT AND REAR COVER

Rear Cover

1. Loosen screws [C] ( x3)

Front Cover

1. Open the Top Cover.

2. Remove screws [A] (

x3)

3. Loosen screws [B] ( x2)

[B]

[A]

[C]
