4
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
4.3
GENERAL INFORMATION
TORQUE SPECIFICATIONS - EFI / FUEL
SYSTEM
EFI / FUEL SYSTEM
ITEM
TORQUE
ECU Retaining Screws 24 in-lb (3 Nm)
Intake Plenum Hose
Clamps
35 in-lb (4 Nm)
Intake Plenum Mount
Screw
22 ft-lb (30 Nm)
Fuel Rail Mounting
Screws
7 ft-lbs (10 Nm)
Fuel PFA Nut
75 ft-lbs (92 Nm)
Fuel Tank Fastener
8 ft-lbs (11 Nm)
Air Box Fastener
8 ft-lbs (11 Nm)
Air Box Gear Clamps 35 in-lbs (4 Nm)
T-MAP Retaining Bolt 7 ft-lbs (10 Nm)
Crankshaft Position
Sensor (CPS) Fastener
9 ft-lbs (12 Nm)
ETC Housing Retaining
Bolts
7 ft-lbs (10 Nm)
Intake Boot Clamp 3 ft-lbs (4 Nm)
Throttle Pedal Mounting
Fasteners
18 ft-lb (24 Nm)
SPECIAL TOOLS - FUEL SYSTEM
PART
NUMBER
TOOL DESCRIPTION
PU-43506-A
Fuel Pressure Gauge Kit
PS-48762
Fuel Pressure Gauge Adapter
PV-48656
Fuel Pressure Gauge Adapter
PU-47063-B
Digital Wrench® Diagnostic Software
(Includes most recent version of
software w/serial number, standard
interface cable, USB-Serial Adapter
cable and SmartLink Module Kit)
PU-47471
Digital Wrench® SmartLink Module Kit
(PU-47470, PU-47469, PU-47468)
PU-47470
Digital Wrench® PC Interface Cable
PU-47469
Digital Wrench® Vehicle Interface
Cable
PU-47468
Digital Wrench® SmartLink Module
Bosch Automotive Service Solutions 1-800-345-2233
or https://polaris.service-solutions.com
FUEL SYSTEM
