9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
8.3
GENERAL INFORMATION
TORQUE SPECIFICATIONS - STEERING /
SUSPENSION
STEERING / SUSPENSION
ITEM
TORQUE
Steering
Steering Wheel Fastener
(Non EPS / EPS)
65 ft-lbs (88 Nm)
Steering Pivot Tube
Fasteners (Non EPS /
EPS)
18 ft-lbs (24 Nm)
Steering Tilt Shock
Fastener (Non EPS /
EPS)
7 ft-lbs (10 Nm)
Steering Shaft to Gear
Box Fastener (Non EPS /
EPS)
36 ft-lbs (49 Nm)
Steering Gear Box
Fasteners (Non EPS /
EPS)
16 ft-lbs (22 Nm)
Steering Shaft to EPS
Fasteners (EPS)
15 ft-lbs (20 Nm)
EPS Unit Base Plate
Screws (EPS)
30 ft-lbs (40 Nm)
EPS Base Plate to Frame
Fasteners (EPS)
19 ft-lbs (26 Nm)
EPS Left Side Bracket to
Frame Fasteners (EPS)
19 ft-lbs (26 Nm)
Front Suspension
Upper A-arm Fastener 73 ft-lbs (99 Nm)
Lower A-arm Fasteners
42 ft-lbs (57 Nm)
Upper Ball Joint Pinch
Fastener
42 ft-lbs (57 Nm)
Lower Ball Joint Castle
Nut
45 ft-lbs (61 Nm)
Front Shock Mounting
Fasteners
42 ft-lbs (57 Nm)
CV Shield Fasteners
Torque Till Seated
Tie Rod Jam Nut
14 ft-lbs (19 Nm)
Tie Rod Fastener
42 ft-lbs (57 Nm)
Front Stabilizer Bar
Fasteners
42 ft-lbs (57 Nm)
STEERING / SUSPENSION
ITEM
TORQUE
Front Stabilizer Support
Fasteners
16 ft-lbs (22 Nm)
Rear Suspension
Upper Control Arm
Fasteners
42 ft-lbs (57 Nm)
Lower Control Arm
Fasteners
42 ft-lbs (57 Nm)
Bearing Carrier Fasteners 42 ft-lbs (57 Nm)
Rear Shock Mounting
Fasteners
42 ft-lbs (57 Nm)
Rear Stabilizer to Linkage
Fastener
42 ft-lbs (57 Nm)
Rear Stabilizer Grease
Zerks Mount Fasteners
31 ft-lbs (42 Nm)
SPECIAL TOOLS - STEERING /
SUSPENSION
PART NUMBER TOOL DESCRIPTION
PA-51600
Ball Joint Separator
PU-50506 Ball Joint Remover / Installer
Bosch Automotive Service Solutions 1-800-345-2233
or https://polaris.service-solutions.com
