4
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
4.15
FUEL TANK
FUEL TANK ASSEMBLY VIEW
q
PFA Nut
75 ft-lbs (92 Nm)
t
PFA Gasket (*replace if removed)
w
Fuel Pump/Regulator
y
Fuel Tank Vent
e
Fuel Sender Float Arm
u
Fuel Tank Mounting Fastener
8 ft-lbs (11 Nm)
r
Fuel Pickup Filter (not serviceable)
i
Fuel Tank Assembly
FUEL SYSTEM
