9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
4.35
CPS REPLACEMENT
1. Access the CPS harness from the right rear side of
the vehicle.
2. Disconnect the CPS harness connector.
3. Remove CPS retaining bolt
q
and remove the sensor
w
from the stator cover.
4. Install new sensor using a light coating of oil on the
O-ring to aid installation.
5. Torque CPS retaining bolt to specification.
TORQUE
CPS Retaining Bolt:
9 ft-lbs (12 Nm)
6. Reconnect CPS harness connector.
FUEL SYSTEM
