2.28
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
COOLANT LEVEL INSPECTION
The pressure cap
q
and recovery bottle
w
are located
under the front storage bin located in the front storage
box. The coolant level must be maintained between the
minimum and maximum levels indicated on the recovery
bottle.
With the engine at operating temperature, the coolant
level should be between the upper and lower marks on
the coolant recovery bottle. If not, perform the following
procedure:
1. Position the vehicle on a level surface.
2. Open the front storage box and remove the storage
bin.
3. View the coolant level in the recovery bottle.
4. If the coolant level is below the MIN line, inspect the
coolant level in the radiator.
NOTE
If overheating is evident, allow system to cool
completely and check coolant level in the radiator and
inspect for signs of trapped air in system.
WARNING
Never remove the pressure cap when the engine is
warm or hot. Escaping steam can cause severe burns.
The engine must be cool before removing the pressure
cap.
5. Remove the pressure cap. Using a funnel, add
coolant to the top of the filler neck.
6. Reinstall the pressure cap.
7. Remove recovery bottle cap and add coolant using a
funnel.
8. Fill recovery bottle to MAX level with recommended
coolant or 50/50 or 60/40 mixture of antifreeze and
distilled water as required for freeze protection in your
area.
Recommended Coolant:
50/50 Extended Life Antifreeze
2880514 (Quart)
2880513 (Gallon)
9. Reinstall the recovery bottle cap.
10.If coolant was required, start engine and check for
leaks. Make sure radiator fins are clean to prevent
overheating.
COOLING SYSTEM PRESSURE TEST
See Cooling System Pressure Test page 3.19
