10
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
10.13
REAR CARGO BOX / FENDERS
q
Rear Cargo Box
i
Underseat Cover Panel LH
w
Rear Fender LH
o
Underseat Cover Panel RH
e
Rear Fender Flare LH
a
PVT Intake Grill
r
Rear Fender RH
s
Engine Intake Grill
t
Rear Fender Flare RH
d
Rubber Grommet
y
Engine Access Panel
f
Push Rivet
u
Cargo Box Access Panel
g
Screw
8 ft-lbs (11 Nm)
BODY / FRAME
