11.8
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
MAIN HARNESS RETENTION LOCATIONS
Front
q
Zip Tie Retention Locations
The white tape on the harness signifies a zip tie retention
point.
Rear
ELECTRICAL
