9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
4.43
COMPONENT CONDITION SPN FMI P-CODE
Driver Circuit Grounded 4 P1265
Driver Circuit Open / Grounded
5 P0264
Rear Differential Output
Driver Circuit Short to B+
746
3 P1692
Driver Circuit Grounded 4 P1693
Driver Circuit Open / Grounded
5 P1691
Fan Relay Driver Circuit
Driver Circuit Short to B+
1071
3 P1482
Driver Circuit Grounded 4 P1483
Driver Circuit Open / Grounded
5 P1481
Ignition Coil Primary Driver 1
(MAG)
Driver Circuit Short to B+ 1268 3 P1353
Ignition Coil Primary Driver 2
(PTO)
Driver Circuit Short to B+ 1269 3 P1354
Fuel Pump Driver Circuit
Driver Circuit Short to B+
1347
3 P0232
Driver Circuit Grounded 4 P0231
Driver Circuit Open / Grounded
5 P0230
ECU Output Supply Voltage 1
Voltage Too High
3597
3 P16A2
Voltage Too Low
4 P16A1
ECU Output Supply Voltage 2
Voltage Too High
3598
3 P16A9
Voltage Too Low
4 P16A8
ECU Output Supply Voltage 3
Voltage Too High
3599
3 P17AA
Voltage Too Low
4 P17AB
ETC Accelerator Position Sensor
Outputs 1 & 2 Correlation
Correlation Fault 65613 2 P1135
Throttle Position Sensor 2
Signal Out of Range
520198
2 P0221
Voltage Too High
3 P0223
Voltage Too Low
4 P0222
All Wheel Drive Control Circuit
(AWD)
Driver Circuit Short to B+
520207
3 P1835
Driver Circuit Grounded 4 P1834
Driver Circuit Open / Grounded
5 P1836
Steering Over Current Shut Down
Current Above Normal or Grounded 520221 6 C1050
Steering Excessive Current Error
Current Above Normal or Grounded 520222 6 C1051
Steering Torque Partial Failure
Condition Exists 520223 31 C1052
Steering Torque Full Failure
Condition Exists 520224 31 C1053
EPS Inverter Temperature
Greater than 120° C (248° F)
520225
0 C1054
Greater than 110° C (230° F)
16 C1055
EPS CAN Communications
Receive Error
No RX Message for 2 Seconds
520226 2 U0100
Position Encoder Error
Bad Intelligent Device Or Component
520228
12 C106A
Condition Exists 31 C106B
EPS Software Error
Software Error
520229
12 C1070
Condition Exists 31 C106F
EPS Power Save Condition
EPS: Key On, Engine Off, 5 Minute
Power Save/Timeout
520231 31 C1071
Accelerator Position / Brake
Position Interaction
Condition Exists 520275 31 P150A
Throttle Position Sensor
(1 or 2 Indeterminable)
Position Sensor Correlation Fault
520276
2 P150B
Neither Position Sensor Passed Test 12 P150C
Throttle Body Control - Power
Stage
Not Plausible
520277
2 P151A
Maximum 3 P150D
FUEL SYSTEM
