9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
6.33
1. Fill Plug 29. Bearing, Ball
57. Shift Collar
2. Drain Plug, Magnetic 30. Bearing, Ball
58. Shift Shaft Rail
3. Screw, M8 x 1.25 x 30
31. Bearing, Ball
59. 1/4 Hose
4. Screw, M6 x 1 x 20
32. Bearing, Ball 60. Shift Dog, Park
5. Screw, M8 x 50
33. Bearing, Needle Cage
61. Shift Forks
6. Screw, M6 x 1 x 40
34. Bearing, Ball
62. Sprocket, 6–Face, See parts
catalog
7. Screw, M6 x 1 x 18
35. Bearing, Ball 63. Low Gear, See parts catalog
8. Nut, NyLoc, M8 x 1.25
36. Wire Harness Bracket
64. Engagement Dog, 6–Face
9. Washer, Cup 37. Spring, Compression 65. Gear, See parts catalog
10. Washer
38. Spring, Compression
66. Pinion
11. Washer
39. Spring, Compression 67. Gear, See parts catalog
12. Washer
40. Cover, Washer
68. Snorkel Gear, See parts catalog
13. Pin, Dowel
41. Snorkel Tube 69. Shift Shaft
14. Pin, Spring
42. Cover
70. Gear, See parts catalog
15. Retaining Ring, External
43. LH Case
71. Rear Mount Bracket, Weldment
16. Snap Ring
44. RH Cover 72. Rear Mount Bracket
17. Retaining Ring, External
45. Shift Drum
73. Bearing Cover
18. Retaining Ring, External 46. Sector Gear, See parts catalog 74. Spacer
19. Retaining Ring, Internal 47. Sector Gear, See parts catalog
75. Silent Chain
20. Retaining Ring, External
48. Pawl
76. Rotary Switch
21. Retaining Ring, External
49. Detent Star
77. O-Ring
22. Retaining Ring, External
50. Park Plate
78. O-Ring
23. Retaining Ring, External 51. Output Assembly 79. O-Ring
24. Washer, Thrust
52. Idler Shaft, See parts catalog 80. Seal, Triple Lip
25. Washer, Thrust
53. Front Output Shaft 81. Seal, Dual Lip, Viton
26. Shim
54. Input Boss Shaft 82. Seal, Triple Lip, Viton
27. Shim
55. Reverse Shaft, See parts catalog 84. Speed Sensor
28. Bearing, Needle Cage
56. Bellcrank
TRANSMISSION
