Polaris ACE 900 XC 2017 User Manual

8
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
8.5
q
Boot Seals
2@
Lock Nuts
7 ft-lbs (10 Nm) Replace with new when removed.
w
Rod Ends
2#
Left Boot
e
Jam Nuts
14 ft-lbs (19 Nm)
2$
Bolts
r
Tie Rods
Not Serviceable
2%
Washers
t
Small Clamps
2^
Flange Nuts
42 ft-lbs (57 Nm) Replace with new when removed.
y
Right Boot
2&
Cotter Pins
Replace with new when removed.
u
Large Clamps
2*
Steering Gear Box
Not Serviceable
i
Shoulder Bolts
2(
Tilt Shock
o
Screw
3)
Pivot Screws
a
Tilt Bushings
3!
Lock Nuts
18 ft-lbs (24 Nm) Replace with new when removed.
s
Steering Bushings
3@
EPS Unit Base Bracket
d
Bolts
3#
Left Side EPS Frame Bracket
f
Steering Bearings
3$
Lower Steering Shaft
g
Steering Wheel
3%
EPS Unit
h
Nut
65 ft-lbs (88 Nm)
3^
Bolts
19 ft-lbs (26 Nm)
j
Cap
3&
Bolts
30 ft-lbs (40 Nm)
k
Pivot Tube
3*
Screw
l
Lock Nuts
Replace with new when removed.
Upper Steering Shaft Pinch Bolts: 15 ft-lbs (20 Nm)
Steering Rack: 16 ft-lbs (22 Nm)
Left Side EPS Bracket to Frame Bolt : 19 ft-lbs (26 Nm)
3(
Screws
1(
Upper Steering Shaft
4)
Washers
2)
Washers
4!
Foam Shield
2!
Lock Nut
36 ft-lbs (49 Nm) Replace with new when removed.
