9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
FUSE / RELAY BOX CIRCUIT TABLE
LOCATION WIRE COLOR DESCRIPTION
1
Red / White Unswitched Fused Battery Voltage, EFI Relay In (Coil High)
2
Red / White Unswitched Fused Battery Voltage, EFI Relay Coil In (Relay In)
3 Orange Key Switch Battery Voltage, Fuel Pump Fuse In (Coil High)
4 Red
Unswitched Battery Voltage, Chassis Relay Power In (Relay In)
5
Red / DK. Blue EFI Battery Voltage, EFI (Relay Out)
6 DK.Green / Yellow EFI Relay Control (Coil Low)
7
White
Switched Battery Voltage, Chassis (Relay Out)
8 Brown / White Ground, Chassis Diode In (Coil Low)
9
Red / DK. Blue EFI Battery Voltage, Fan Relay Coil Power (Coil High)
10 Red
Unswitched Battery Voltage, Fan (Relay In)
11 White
Switched Battery Voltage, Lights 20A Fuse (In)
12 Red
Key Switch Battery Voltage, Chassis Relay Coil Power, Fuel Pump
10A Fuse (In)
13 Orange / Black Fan, Battery Voltage, Fan (Relay Out)
14
Orange / White Fan Relay Control (Coil Low)
15 Red / Yellow Lights, 20A Fuse Protected (Out)
16
Red / Green Fuel Pump, 10A Fuse Protected (Out)
17
Red / DK. Blue Fuel Pump Relay Coil Power (Coil High)
18 Red / Green Fuel Pump Fused Relay, Battery Voltage (Relay In)
19 White
Switched Battery Voltage, Drive Fuse 20A (In)
20 Red
Unswitched Battery Voltage, EFI Fuse 20A (In)
21 Red / Blue Fuel Pump (Relay Out)
22
DK. Green / Yellow Fuel Pump Relay Control (Coil Low)
23 Red / DK. Green Switched Battery Voltage, Drive 20A Fused (Out)
24
Red / White Unswitched Battery Voltage, EFI Fused 20A (Out)
25
Orange Brake Fuse 5A (In)
27 White
Switched Battery Voltage, Accessory Fuse 20A (In)
28 Red
Unswitched Battery Voltage, Chassis Relay Power Fuse 30A (In)
29 Orange Brake Fuse 5A (Out)
31
Orange / White Accessory Battery Voltage, Fused 20A (Out)
32 Red / Black Unswitched Battery Voltage, Chassis Relay Power In, Chassis Fused
30A (Out)
33
Orange Key Switched Battery Voltage (In) - OPTION
34 Red
Battery Voltage, EPS Fuse Protected 30A (In) - OPTION
35 Red
Unswitched Battery Voltage, EPS Fuse 30A (In) - OPTION
36
Red / Brown Unswitched Battery Voltage, Fan Circuit Breaker 20A
37
Orange EPS Controller Battery Voltage (Out) - OPTION
38 Brown
Relay Ground (Out) - OPTION
39 Red
EPS Battery Voltage, Fused 30A (Out) - OPTION
40 Red
Unswitched Battery Voltage, Fan Relay Power In, Circuit Breaker 15A
ELECTRICAL
