3.24
9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
CRANKSHAFT PTO SEAL REPLACEMENT
Special Tool PU-52493 allows the replacement of the
engine crankshaft PTO seal without splitting the engine
case.
IMPORTANT
PU-52493 is specifically designed for 2018 engines and
does NOT work with 2017 and older models.
CRANKSHAFT PTO SEAL REMOVAL
1. Remove the Inner PVT Cover. Refer to PVT
disassembly to access the crankcase seal.
2. Using a commercially available seal puller tool,
remove crankcase seal from crankcase.
IMPORTANT
Use care not to scratch the crankcase while removing
seal.
3. Inspect the crankcase and crankshaft surfaces for
any burrs or scratches that could damage the new
seal or prevent it from sealing properly.
ENGINE / COOLING SYSTEM
