11.86

9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual

AWD / 2WD / TURF SWITCH TESTING

1. Disconnect the AWD / 2WD / TURF switch harness

by depressing the connector locks and pulling on the

connector. Do not pull on the wiring.

2. Test between the 3 sets of outputs (AWD / 2WD /

TURF). If any of the tests fail, replace the switch

assembly.

• Move the switch to AWD. There should be continuity

between switch pins 2 and 3.

• Move the switch to 2WD. There should be no

continuity between any pins.

• Move the switch to TURF. There should be continuity

between switch pins 1 and 2.

NOTICE

Pins 7 and 2 provide power and ground to light the

switch lamp.

TRANSMISSION / GEAR POSITION SWITCH

TESTING

1. The transmission (gear position) switch

is located

on the RH side of the transmission and can be

accessed through the rear RH wheel well area.

ELECTRICAL
