9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
7.49
17.Rotate front of gearcase up so the input shaft is
facing down. Lift and remove the gearcase from the
front LH wheel well area and slide it out of the vehicle
above the upper A-arm.
FRONT GEARCASE DISASSEMBLY /
INSPECTION
1. Drain and properly dispose of gearcase fluid.
Remove any metal particles from the drain plug
magnet.
2. Remove the seven cover screws and remove the
cover plate assembly.
3. Remove the LH output hub assembly from the clutch
housing or outer cover plate assembly.
IMPORTANT
Nylon spacer is non-serviceable and should not be
removed.
FINAL DRIVE
