SERVICE SPECIFICATIONS - ELECTRICAL
SYSTEM
PART DESCRIPTION
SERVICE
SPECIFICATION
Stator Leg to Leg
Resistance
0.07 - 0.13 Ω
Stator Leg to Ground
Resistance
Open Line (OL / ∞)
Stator Leg Voltage (1300
RPM)
21 VAC ± 25%
Stator Leg Voltage (3000
RPM)
47 VAC ± 25%
Stator Leg Voltage (5000
RPM)
79 VAC ± 25%
Starter Solenoid Terminal
Resistance (77 °F)
0 - 0.5 Ω
CPS Resistance 1000 Ω ± 10%
ECT Resistance (77 °F /
25 °C)
29.9 kΩ ± 6%
ECT Resistance (248 °F /
120 °C)
1.22 kΩ ± 2%
AWD Hub Coil Resistance 24 Ω ± 5%
Current Draw - Key Off
(Max)
.01 DCA (10 mA)
