11.20
9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION - ELECTRICAL SYSTEM
SERVICE NOTES - ELECTRICAL SYSTEM
WARNING
CALIFORNIA PROPOSITION 65 WARNING:Batteries,
battery posts, terminals and related accessories contain
lead and lead compounds, and other chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. WASH HANDS
AFTER HANDLING.
WARNING
Battery electrolyte is poisonous. It contains acid!
Serious burns can result from contact with the skin,
eyes, or clothing.
ANTIDOTE:
External: Flush with water.
Internal: Drink large quantities of water or milk. Follow
with milk of magnesia, beaten egg, or vegetable oil. Call
a physician immediately.
Eyes: Flush with water for 15 minutes and get prompt
medical attention.
Batteries produce explosive gases. Keep sparks, flame,
cigarettes, etc. away. Ventilate when charging or using
in closed space. Always shield eyes when working near
batteries.
Keep out of reach of children.
Keep the following notes in mind when diagnosing an
electrical problem:
• Refer to wiring diagram for stator and electrical
component resistance specifications.
• When measuring resistance of a component that has a
resistance value under 10 Ohms, remember to
subtract meter lead resistance from the reading.
Connect the leads together and record the resistance.
The resistance of the component is equal to tested
value minus the lead resistance.
• Become familiar with the operation of your meter. Be
sure leads are in the proper jack for the test being
performed (i.e. 10A jack for current readings). Refer to
the Owner’s Manual included with your meter for more
information.
• Voltage, amperage, and resistance values included in
this manual are obtained with a Fluke™ 77 Digital
Multimeter (PV-43568). This meter is used when
diagnosing electrical problems. Readings obtained
with other meters may differ.
• Pay attention to the prefix on the multimeter reading
(K, M, etc.) and the position of the decimal point.
• For resistance readings, isolate the component to be
tested. Disconnect it from the wiring harness or power
supply.
The following components can be accessed under the
hood.
• Voltage Regulator (in front of radiator)
• Terminal Block
• Headlight Connectors
The following components can be accessed with the
upper dash panel removed.
• Instrument Cluster (Speedometer)
• AWD/2WD/TURF Switch
• Headlight Switch
• 12 VDC Accessory Power Points
• Ignition Key Switch
The following components can be accessed with the
passenger seat base removed.
• Battery*
• Battery Cables*
• Starter Solenoid*
• Relays*
ELECTRICAL
