7.18
9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
8. Slide the rear propshaft forward to remove it from the
transmission output shaft.
9. Lift the support bearing and propshaft upward and
push towards rear of the vehicle until it clears its
mount.
NOTICE
If necessary, separate the support bearing to gain
clearance.
NOTICE
The rear of the propshaft must be angled and guided
backwards to aid in clearing the mount.
10.Angle the front of the propshaft and support bearing
downward and move toward the front of the vehicle to
remove.
CAUTION
Use care not to damage brake lines when removing
propshafts.
11. With the propshafts removed from the vehicle,
inspect the shaft for cracks, damage from debris, and
straightness.
FINAL DRIVE
