6. Gently tap bearing cap removal tool up with rubber
mallet.
7. Remove the bearing cap removal tool and retaining
ring.
8. Install a commercially available Internal Floating
Piston (IFP) into the shock reservoir.
9. Press the bearing assembly down with your fingers.
At the same time push the IFP tool upwards with your
thumbs.
10.Remove the bearing cap retaining ring with a valve
shim.
11. Remove shock shaft assembly by pushing down on
the IFP removal tool while pulling up on shock shaft
assembly.
12.Dump out used oil.
13.Using a 9/16-inch open end wrench and a 1/8-inch
Hex Tee handle wrench, remove the bleed screw.
STEERING / SUSPENSION
