Polaris RZR 570 2015 Service Manual

11.22
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
STATOR (ALTERNATOR) REPLACEMENT
Refer to Chapter 3 (Engine / Cooling System) to service
the stator.
NOTE
The stator cover can be removed with the engine
installed in the chassis.
Be sure to thoroughly drain the engine coolant and
clean the area around the stator cover prior to removal.
See chapter 3.
REGULATOR / RECTIFIER
The Regulator / Rectifier is located in the left rear wheel
well area in front of the left rear wheel. It is mounted
under the LH panel divider, below the ECU.
ELECTRICAL
