1.24
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
MISC. SPECIFICATIONS AND CHARTS
MASTER TORQUE TABLE
ITEM
TORQUE
A-Arm Bolt
39 ft-lb (53 Nm)
Ball Joint Pinch Bolts
(Front)
23 ft-lb (31 Nm)
Bearing Carrier Nuts
(Rear)
40 ft-lb (54 Nm)
Bearing Retaining Plate
Screws
8 ft-lbs (11 Nm)
Bell Crank Nut
15 ft-lbs (20 Nm)
Brake Disc Mounting Bolts
(Front)
18 ft-lbs (24 Nm)
Brake Disc Mounting Bolts
(Rear)
28 ft-lbs (38 Nm)
Brake Bleed Screws
47 in-lbs (5 Nm)
Brake Caliper Mounting
Bolts (Front)
30 ft-lbs (41 Nm)
Brake Caliper Mounting
Bolts (Rear)
44 ft-lbs (60 Nm)
Brake Line Junction Block
Mounting Screws
36 in-lbs (4 Nm)
Brake Line Banjo Bolts
(Master Cylinder and
Caliper Attachment)
15 ft-lbs (20 Nm)
Brake Line Flare Fittings 14 ft-lbs (19 Nm)
Brake Pedal Mount
Bracket Bolts
17 ft-lbs (23 Nm)
Brake Rotor Bolts
30 ft-lbs (41 Nm)
Brake Switch
14 ft-lbs (19 Nm)
Cab Frame Bolts
28 ft-lb (38 Nm)
Cam Chain Tensioner
30 ft-lb (40 Nm)
Camshaft Carrier Bolts
7.5 ft-lb (10 Nm)
Camshaft Sprocket Bolts 14 ft-lb (19 Nm)
Clutch Cover (outer)
Screws
100 in-lbs (12 Nm)
Clutch Spring Retaining
Ring Bolts
11 ft-lbs (15 Nm)
Coolant Bleed Screw
6 ft-lbs (8 Nm)
Coolant Temperature
Sensor
17 ft-lb (23 Nm)
CPS Retaining Bolt 9 ft-lb (12 Nm)
Cylinder Head Bolts -
Black
Torque in sequence for all
steps
Step 1: 21 ft-lbs (28 Nm)
Step 2: 26 ft-lb (35 Nm)
ITEM
TORQUE
Step 3: Additional 135°
Torque The Outer M6 Head
Bolts 89 ± 9 in-lbs (10 ± 1
Nm)
Cylinder Head Bolts -
Silver
Torque in Sequence for all
steps
Step 1: 18 ft-lbs (25 Nm)
Step 2: 30 ft-lbs (40 Nm)
Step 3: Loosen all
fasteners until they are
unseated
Step 4: 15 ft-lbs (20 Nm)
Step 5: 26 ft-lbs (35 Nm)
Step 6: Additional 180°
Step 7: Additional 180°
Torque The Outer M6 Head
Bolts 89 ± 9 in-lbs (10 ± 1
Nm)
Differential Cover Screws
(INTL)
21 ft-lb (28 Nm)
Drive Clutch Retaining Bolt 47 ft-lbs (64 Nm)
Drive Clutch Cover Plate
Screw
100 in-lb (12 Nm)
Drive Clutch Spider
225 ft-lb (305 Nm)
(Apply 0.4 mL Loctite® 7088
Primer and 0.4 mL Loctite®
620™)
Driven Clutch Retaining
Bolt
36 ft-lbs (49 Nm)
Driven Clutch Cover
Screws
10 ft-lb (14 Nm)
ECU Mounting Screws 10 in-lb (1 Nm)
Engine Mount (front) 40 ft-lbs (54 Nm)
Engine Oil Plug 12 ft-lbs (16 Nm)
Engine to Transmission
Coupler Bolts
55 ft-lbs (75 Nm) *see
procedure for illustration
Exhaust Head Pipe Bolts 18 ft-lb (25 Nm)
Floor Screws
5 ft-lb (7 Nm)
Flywheel Retaining Nut 133 ft-lbs (180 Nm)
Front Bumper / Fender
Screws
8 ft-ln (11 Nm)
Front Gearcase Cover
Plate Screws
9 ft-lbs (12 Nm)
Front Gearcase Drain/Fill
Plugs
10 ft-lbs (14 Nm)
GENERAL INFORMATION
