ITEM
TORQUE
Front Gearcase Mounting
Bolts
30 ft-lbs (41 Nm)
Fuel Pump PFA Nut 70 ft-lbs (95 Nm)
Fuel Rail Mounting Screws 7 ft-lbs (10 Nm)
Fuel Tank Mounting
Screws
17 ft-lbs (23 Nm)
Gear Sector Cover
11 ft-lbs (15 Nm)
Hip Bolster Bolts 8 ft-lb (11 Nm)
Hose Clamp 36 in-lb (4 Nm)
IAC Mounting Screw 18 in-lbs (2 Nm)
Master Cylinder Mount
Bolts
17 ft-lbs (23 Nm)
Oil Filter
6 ft-lbs (8 Nm)
Oil Filter Adapter
Fasteners
20 ft-lbs (28 Nm)
Oil Pump Cover Bolts 7 ft-lbs (10 Nm)
Oil Pump Sprocket Bolts 9 ft-lbs (12 Nm)
Parking Brake Assembly
Bolts
37 ft-lbs (50 Nm)
Parking Brake Disc
Mounting Bolts
21 ft-lbs (28 Nm)
Parking Brake Disc
Mounting Bolts (INTL)
8 ft-lbs (11 Nm)
Park Flange Screws 8 ft-lbs (11 Nm)
Parking Brake Lever
Mounting Bolts
16 ft-lbs (22 Nm)
Parking Brake Mount
Bracket to Transmission
Bolts
37 ft-lbs (50 Nm)
Power Steering Bracket to
Frame Nuts
14 ft-lb (19 Nm)
Power Steering Unit to
Mount Bracket
30 ft-lb (42 Nm)
Prop Shaft Support
Bearing Fasteners
30-36 ft-lbs (41-49 Nm)
PVT Inner Cover Bolts
12 ft-lbs (16 Nm)
PVT Outer Cover Bolt
50 in-lbs (5 Nm)
Seat Base to Seat Frame
Fasteners
40 ft-lbs (54 Nm)
Seat Base to Frame (front) 40 ft-lb (54 Nm)
Seat Base to Frame (rear) 40 ft-lb (54 Nm)
Seat Belt Mounting
Fasteners
40 ft-lbs (54 Nm)
Seat Belt to Seat Base
40 ft-lbs (54 Nm)
Shift Cable Bracket Bolts
17 ft-lbs (23 Nm)
Shock Mount Bolts
37 ft-lb (50 Nm)
ITEM
TORQUE
Skid Plate Fasteners
8 ft-lbs (11 Nm)
Snorkel Tube
Refer to “Snorkel Gear
Backlash Procedure”
Snorkel Tube Locking
Screw
8 ft-lbs (11 Nm)
Spark Arrestor Fasteners 8 ft-lbs (11 Nm)
Spark Plug 9 ft-lbs (12 Nm)
Speed Sensor Screw 8ft-lbs (11 Nm)
Stabilizer Bushing
Retaining Nut
37 ft-lbs (50 Nm)
Stabilizer Bar Linkage
(rear)
37 ft-lbs (50 Nm)
Stabilizer Bar Mounting
Bracket Bolts (rear)
18 ft-lb (24 Nm)
Starter Mounting Bolts 7 ft-lb (10 Nm)
Starter One-Way Clutch
Screws
9 ft-lbs (12 Nm)
Apply Loctite® 272™
Stator Cover Screws
9 ft-lb (12 Nm)
Stator Wire Routing Bolts
6 ft-lbs (9 Nm)
Apply Loctite® 242™
Steering Tilt Shock
Fastener (Lower)
12 ft-lb (16 Nm)
Steering Tilt Shock
Fastener (Upper)
7 ft-lbs (10 Nm)
Steering Pivot Tube
Fasteners
23 ft-lb (31 Nm)
Steering Rack Mounting
Bolts
16 ft-lbs (22 Nm)
Steering Shaft to EPS Unit 16 ft-lbs (22 Nm)
Steering Shaft to Steering
Rack
36 ft-lb (48 Nm)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Thermostat Cover Bolts
7 ft-lbs (10 Nm)
Throttle Pedal Mounting
Fasteners
8 ft-lb (11 Nm)
Tie Rod End Jam Nuts
13 ft-lbs (18 Nm)
Tie Rod End Fastener
43 ft-lb (58 Nm)
T-MAP Retaining Bolt 24 in-lbs (2.8 Nm)
TPS Mounting Screws 18 in-lbs (2 Nm)
Transmission Bell Crank
Nut
15 ft-lb (20 Nm)
Transmission Case Bolts
17 ft-lbs (23 Nm)
Transmission Drain / Fill
Plugs
12 ft-lbs (16 Nm)
Transmission Isolator
Bolts (Rear)
40 ft-lbs (54 Nm)
