Polaris RZR 570 2015 Service Manual

1.26
9926813 R04 - 2013-2016 RZR 570 Service Manual
© Copyright Polaris Industries Inc.
ITEM
TORQUE
Transmission Rear Mount
Bracket Fasteners
17 ft-lb (23 Nm)
Transmission Park Flange
Screws
8 ft-lb (11 Nm)
Transmission Sector Gear
Cover
11 ft-lb (15 Nm)
Transmission Shift Fork
Screws
8 ft-lb (11 Nm)
Transmission Snorkel
Tube Locking Screw
8 ft-lb (11 Nm)
Valve Cover Bolts
9 ft-lbs (12 Nm)
Voltage Regulator
Fasteners
75 in-lb (6 Nm)
Water Pump Cover Bolts
9 ft-lb (12 Nm)
(Apply Loctite® 204™ to bolt
threads)
Wheel Hub Castle Nuts
(Front)
80 ft-lb (108 Nm)
Wheel Hub Castle Nuts
(Rear)
110 ft-lbs (149 Nm)
Wheel Lug Nuts
Steel Rims: 27 ft-lbs (37
Nm)
Aluminum Rims: 30 ft-lbs
(41 Nm) + 90°
GENERAL INFORMATION

Polaris RZR 570 2015 Specifications

General

Brand	Polaris
Model	RZR 570 2015
Category	Offroad Vehicle
Language	English
