Microphones and Speakers
Polycom, Inc. 4–11
Connecting Speakers to Polycom HDX 9000 Series Systems
The following table describes the audio outputs of the Polycom HDX 9000
series system.
Connecting Speakers to Polycom HDX 8000 Series Systems or
Polycom HDX 7000 HD Systems with Hardware Versions A, B, or C
The following table describes the audio outputs of Polycom HDX 8000 series
systems or Polycom HDX 7000 series systems with Hardware Versions A, B,
and C.
Connecting Speakers to Polycom HDX 7000 HD Systems with
Hardware Version D
The following table describes the audio output of Polycom HDX 7000 HD
systems with Hardware Version D.
Audio Output Number Connector Output Type Audio Mix Routed to the Output
1 (Main Audio) Phoenix Mono/Stereo System tones and sound effects +
Audio from the far site +
Content audio connected to audio input 3 (and 4 for
Polycom HDX 9004)
3 (VCR/DVD Player) Phoenix Mono/Stereo Near-site talkers +
Audio from the far site +
Content audio connected to audio input 3 (and 4 for
Polycom HDX 9004)
Audio Output Number Connector Output Type Audio Mix Routed to the Output
1 (Main Audio) RCA Mono/Stereo System tones and sound effects +
Audio from the far site +
Content audio connected to audio input 3
3 (VCR/DVD Player) RCA Mono/Stereo Near-site talkers +
Audio from the far site +
Content audio connected to audio input 3
Audio Output Number Connector Output Type Audio Mix Routed to the Output
1 (Main Audio) RCA Mono/Stereo System tones and sound effects +
Audio from the far site +
Content audio connected to audio input 3
