Polycom HDX 8000 series User Manual

Networks
Polycom, Inc. 2–33
3 Select if necessary and select a channel to activate or deactivate it.
Active channels are represented by a green icon, and inactive channels
are represented by a gray icon.
Configuring the Serial V.35/RS-449/RS-530 Network Interface
To configure the V.35/RS-449/RS-530 network interface settings:
1 Do one of the following:
— In the local interface, go to System > Admin Settings > Network >
V.35/RS-449/RS-530 (select if necessary).
— In the web interface, go to Admin Settings > Network >
V.35/RS-449/RS-530.
2 Configure these settings:
PRI Line Type Displays read-only information about the system and its
configuration.
Number of
Active Channels
D Channel
Location
Network Mode
Clock Source
Terminal
Endpoint ID
TEI
Line Termination
PRI E1 only
Setting Description
Make sure that channels are activated and deactivated only by a knowledgeable
network professional so that the system operates properly and can dial at the
desired rates.
Setting Description
Enable
V.35/RS-449/RS-530
Allows the system to connect to a terminal adapter using
a V.35, RS-449, or RS-530 connection.
V.35 Ports Used Specifies whether one or two lines are connected.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Polycom HDX 8000 series Specifications

General

Microphone	Polycom HDX Microphone Array
Network Protocols	H.323, SIP
Network Interface	10/100/1000 Ethernet
Network Interfaces	10/100/1000 Ethernet
Video Standards	H.263, H.264
Video Resolution	720p, 1080p
Content Sharing	H.239, People+Content
Audio Standards	G.711, G.722, G.728, G.729A
Encryption	H.235 (AES)
Camera	Polycom EagleEye HD camera
Data Standards	H.239
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI, DVI-I
Audio Inputs	3.5mm stereo line-in
Audio Outputs	RCA
Display Outputs	HDMI, DVI-I
