Digital Microphone Array Numbering
Examples of the microphone connections and their numbering within Sound-
Structure are shown in the following figure.
PIN 2: TXD
PIN 3: RXD
PIN 5: GROUND
PIN 7: CTS
PIN 8: RTS
LAN
C-LINK2
OBAM IR
RS-232
REMOTE CONTROL 2
IN OUT
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
OUTPUTS INPUTS
SoundStructure C16
TM
12V
REMOTE CONTROL 1
PIN 2: TXD
PIN 3: RXD
PIN 5: GROUND
PIN 7: CTS
PIN 8: RTS
LAN
C-LINK2
OBAM IR
RS-232
IN OUT
12V
POLYCOM POLYCOM POLYCOM POLYCOM
POLYCOM POLYCOM
HDX Mic 1 HDX Mic 2 HDX Mic 3 HDX Mic 4
HDX Mic 1 HDX Mic 2
