SECTION III: SIZING AND PERFORMANCE
PoolPak Unit Dimensions and Weights
Figure 3-1. MPK Dimensional Isometric View
RETURN AIR (BOTTOM)
INTEGRAL AUXILIARY
HEAT MODULE
SUPPLY AIR
EXHAUST AIR
BASE MPK UNIT
OUTSIDE AIR
LENGTH (L)
LENGTH (L)
LENGTH (L)
LENGTH (L)
(H)
H
E
I
G
H
T
WIDTH (W)
LENGTH (L)
INTEGRAL AUXILIARY
HEAT MODULE
BASE MPK UNIT
RIGHT
VIEW
FRONT
VIEW
REAR
VIEW
INTEGRAL AIR COOLED
CONDENSER
LEFT
VIEW
INTEGRAL AIR COOLED
CONDENSER
AIR FLOW
Refer to project specific unit drawings for dimensions and weights.
