Table 3-3. PoolPak Provided Remote ACC Specifications
Note: Below table contains the piping sizes of the remote ACC stub-outs. Additional field piping may be needed
to make the transition from the ACC connections to correct refrigeration lineset sizing (See Table 4-1).
Remote ACC product drawings are available on the PoolPak website in the MPK Product Drawings folder
PoolPak Remote ACC Specifications
Non-PoolPak Provided Air-Cooled Consenser Selection Procedure
The procedure for selecting an optional remote air-cooled condenser is:
1. Find the unit’s total heat rejection capacity from the MPK Unit Performance table.
EXAMPLE (for MPK D060):
Heat Rejection Capacity = 927,271 Btu/hr
2. Determine the difference between 120°F (the design condensing temperature)
and the design outdoor dry bulb temperature.
3. For the given Heat Rejection Capacity and temperature difference (from step 2),
select the proper sized condenser using R-410A refrigerant.
Refrig Sys
Size
Ambient
Air Temp
ACC Model
Fan Qty Refrigerant Connection Sizes
Weight ACC Voltage FLA MCA MOP
wide long
Circuit 1 Circuit 2 Circuit 3
Gas
Liq Gas Liq Gas Liq
030
95/100/
105
MAC0532 2 2 1-3/8 7/8 1-3/8 7/8
- - 3,170
208/230-3-60 36 38.3 45
460-3-60 18 19.1 25
575-3-60 15.2 16.1 20
035
95/100/
105
MAC0602 2 2 1-3/8 7/8 1-3/8 1-1/8 - - 3,220
208/230-3-60 36 38.3 45
460-3-60 18 19.1 25
575-3-60 15.2 16.1 20
040
95/100/
105
MAC0682 2 2 1-3/8 7/8 1-5/8 1-1/8
- -
3,300
208/230-3-60 36 38.3 45
460-3-60 18 19.1 25
575-3-60 15.2 16.1 20
045
95/100/
105
MAC0742 2 2 1-3/8 1-1/8 1-5/8 1-1/8
- -
3,330
208/230-3-60 36 38.3 45
460-3-60 18 19.1 25
575-3-60 15.2 16.1 20
050
95/100/
105
MAC0842 2 2 1-3/8 1-1/8 1-5/8 1-3/8
- -
3,370
208/230-3-60 36 38.3 45
460-3-60 18 19.1 25
575-3-60 15.2 16.1 20
060
95/100/
105
MAC1003 2 3 1-3/8 1-1/8 1-3/8 1-1/8 1-3/8 1-1/8 3,730
208/230-3-60 54 56.3 60
460-3-60 27 28.1 30
575-3-60 22.8 23.8 25
070
95/100/
105
MAC1163 2 3 1-3/8 1-1/8 1-5/8 1-1/8 1-5/8 1-1/8 3,920
208/230-3-60 54 56.3 60
460-3-60 27 28.1 30
575-3-60 22.8 23.8 25
080
95/100/
105
MAC1353 2 3 1-5/8 1-1/8 1-5/8 1-1/8 1-5/8 1-3/8 4,050
208/230-3-60 54 56.3 60
460-3-60 27 28.1 30
575-3-60 22.8 23.8 25
090
95/100/
105
MAC1483 2 3 1-5/8 1-1/8 1-5/8 1-3/8 1-5/8 1-3/8 4,100
208/230-3-60 54 56.3 60
460-3-60 27 28.1 30
575-3-60 22.8 23.8 25
