SECTION VI: WIRING
Remote Connections Schematic
Figure 6-1. PoolPak Control Panel
ECC III
DC
POWER
SUPPLY
FACTORY WIRING
FACTORY WIRING
FIELD WIRING
PRESSURE
MODULE
REMOTE INTERFA
CE UNIT
SPECIAL
CABLE
(BY POOLPAK)
3 LINE TELEPHONE
JACK (BY POOLPAK)
FACTORY WIRING
REMOTE DISPLAY
CONNECTION
BACnet/IP AND/OR
REMOTE ACCESS
ENTERNET
CONNECTION
CONTROL
MODULE CM1
CM2
CM3
CM4CM5
CM6
FACTORY WIRING
FACTORY WIRING
AND TUBING
CUTOUT
CONTROL
TRANSFORMERS
AIRFLOW
PRESSURE
TRANSDUCERS
T16
T15 T17
- 3 WIRES
- 24 GAUGE MIN
- 500 FT MAX LENGTH
- 3 WIRES
- 24 GAUGE MIN
- 500 FT MAX LENGTH
- 6 WIRES
- 24 GAUGE MIN
- 1000 FT MAX LENGTH
BUILDING
AUTOMATION
SYSTEM (BAS)
MULTIPLE UNIT NETWORK
CONNECTION
CATEGORY 5
TWISTED PA IR
CATEGORY 5
TWISTED PAIR
CATEGORY 5
TWISTED PA IR
CONVENIENCE
OUTLET
