POSEIDON Jetstream Service Manual

1.0:E132
JET/CYK
3580 First stage, Jetstream
3585 First stage, Cyklon 5000
Pos. No.
13417
22802
33418
42814
53419
61189
72816
82817
92782
10 2679
11 3581
12 3587
13 3024
14 1156
15 2803
16 2820
17 2821
18 1368
19 2822
20 2809
21 2823
22 3388
23 3387
24 1562
25 2807
26 2402
27 3096
28 1007
29 2656
30 1377
31 2827
32 1839
33 2828
34 2966
35 2778
36 1287
37 1286
38 2918
39 2680
40 3294
41 3293
42 1095
43 3292
44 3291
Adjusting screw
Pressure spring, outer
Pressure spring, inner
Cover
Diaphragm centre, upper
Diaphragm
Diaphragm centre, lower
Valve needle
O-ring (7 pcs)
Blind screw UNF 3/8'' (4 pcs)
Valve housing
Restrictor screw for first stage
No. 3585 Cyklon 5000
Blind screw M 7x1
O-ring
Valve seat
Valve piston
Spacing sleeve
O-ring
Washer
O-ring
Balanced housing
Spring guidance
Pressure spring
O-ring
Blind screw G 1/8
Protective cup
Locking screw
O-ring
O-ring (2 pcs)
Cup-type filter
Connection
O-ring
Wheel G 5/8
Connection incl. 27-33
Locking strap*
Anti-freeze cap*
Anti-freeze cap incl. 35-36*
O-ring
Blind screw UNF 7/16''
Spacer ring
Banjo housing
Restrictor screw
Banjo screw
Banjo coupling UNF 7/16''
incl. 9, 38, 40-43
