CYKLON
1.0:E66
FIRST STAGE
3070, 2422
1. Install the o-ring (22) on the cup
type 21), then install the locking
screw and o-ring (23). Tighten
with a 6 mm Allen wrench.
FIRST STAGE
2305
1. Install the cup filter (18) and
the locking screw (19) with a
8.5 mm screwdriver.
Install the o-ring (20).
2. Install the o-ring (9) on the LP
hose. Lubricate the o-ring and
the thread.Tighten the hose
nipple with a 13 mm openend
wrench.
INSTALLMENT OF ANTIFREEZE CAP
1. Check valve cover for correct tightness - 28-30 Nm.(20-22 lbf.ft)
2. Blow the inside of the valve cover clean and dry.
3. Then fill the valve cover and the rubber with pure
spirit (alcohol, vodka) or water/glycol mixture. 3/4 fill.
4. Install the anti-freeze cap and fasten it with the locking band.
