POSEIDON Jetstream Service Manual

1.0:E140
TRITON
3880 First stage G5/8”
Pos. No. Description
13417 Adjusting screw
22802-10Secondary spring
42814 Cover for valve housing
53419 Upper diaphragm centre
63723 Valve centre upper for 3720
73724 Diaphragm for 3720
82816 Diaphragm centre,lower
92817-10Valve needle (29,5) for 3720
10 3722 Valve centre, lower for 3720
11 3728 O-ring
12 2809 O-ring*
13 1156 O-ring
14 2803 Valve seat
15 2820-10 Valve piston
16 1180 Pressure spring
17 3160 Support washer
18 1368 O-ring
19 2822 Washer
20 3721 Valve housing
21 2402 Protective cap G 5/8”
22 3096 Locking screw
23 2656 O-ring
24 1007 O-ring
25 1377 Cup type filter
26 2827 Connection
27 1839 O-ring
28 2828 Wheel G 5/8”
29 2679 Blind screw 300 bar, UNF 3/8 (3 pcs)
30 2782 O-ring (3 pcs)
31 2680 Blind screw 300 bar, UNF 7/16 (2 pcs)
32 2918 O-ring (2 pcs)
33 3726 Valve sealing
34 3725 Valve piston
35 3727 Locking screw
36 2778 Locking strap
1)
37 1287 Rubber cap
1)
38 1286 Anti freeze cap
1)
39 2923 Pressure spring
1)
accessories
* only for first stage 3790
