Poseidon Cyklon 300
BREATHING REGULATOR Art. No 2980
Primary pressure ................................................................................Max. 4350 PSI / 300 bar
Secondary pressure ..........................................................................Max. 181 PSI / 12.5 bar
Air flow ..................................................................................................Approximately 800 l/min
Inhalation resistance at 115 l/min...............................................Max. 40 mm of water
Exhalation resistance .......................................................................Max. 20 mm of water
The above data apply when measuring at atmospheric pressure
FIRST STAGE VALVE Art. No 3070
Description...........................................................................................Diaphgram-operated,
compensated
Connection threads for primary pressure................................G 5/8’’ -max. 4350 PSI / 300 bar
Outlet connections:
Four outlets marked LP for second stage,
drysuits, buoyancy compensators, hookah
supply, safety second stage, etc ...................................................UNF 3/8’’ -secondary pressure
One outlet marked HP.....................................................................UNF 7/16’’-primary pressure
SECOND STAGE VALVE
Type designation ...............................................................................Art. No 1133, 3536
Description...........................................................................................Downstream type, diaphragm actuated.
Integral saftey valve opens at
approximatley 203 PSI / 14 bar.
Purge button for clearing.
REGULATOR HOSE Art. No 2946
Length....................................................................................................28 inch / 70 cm
TIGHTENING TORGQUE
Primary connection ..........................................................................20-22 Ibf.ft / 28-30 Nm
Valve cover ...........................................................................................20-22 Ibf.ft / 28-30 Nm
Connections marked LP-HP...........................................................6 Ibf.ft / 8 Nm
ANTI-FREEZE PROTECTION
Type designation ...............................................................................Art. No 1286
Type ........................................................................................................Rubber cap
CYKLON
1.0:E45
