Poseidon Cyklon 5000
BREATHING REGULATOR Art. No 2950
Primary pressure ................................................................................Max. 4350 PSI / 300 bar
Secondary pressure ..........................................................................Max. 174 PSI / 12 bar
Air flow ..................................................................................................Approx. 1050 l/min
Inhalation resistance at 115 l/min...............................................Max. 40 mm of water
Exhalation resistance ......................................................................Max. 20 mm of water
The above data apply when measuring at atmospheric pressure
FIRST STAGE VALVE Art. No 3257, 3585
Description...........................................................................................Diaphgram-actuated, balanced.
Connecting threads for primary pressure................................G 5/8 -max 4350 PSI /300 bar accord.
SS 2600/K and DIN 477/5 or yoke connection
accord. SS 2603 and ANSI/CGA VI: 1987
Outlet connections:
One outlet marked R for second stage (max airflow)..........UNF 3/8’’ - secondary pressure
Three outlets marked LP for drysuits, buoyancy
compensators, hookah supply, safety second stage etc.....UNF 3/8’’ -secondary pressure
One outlet marked S has restricted airflow
and therefore is intended only for dry-suit or stabjacket ..Intended for first stage No. 3585
UNF 3/8’’ -secondary pressure
One outlet marked HP for pressure gauge..............................UNF 7/16’’ -primary pressure
SECOND STAGE VALVE Art. No 1133
Description...........................................................................................Downstream-type, diaphragm actuated.
Integral safety opens with approximately
203 PS1/14 bar. Purge button for clearing.
REGULATOR HOSE
Length....................................................................................................28 inch / 70 cm
TIGHTENING TORQUE
Primary connection ..........................................................................20 - 22 Ibf.ft / 28-30 Nm
Valve cover ...........................................................................................20 - 22 Ibf.ft / 28-30 Nm
Connections marked R-LP-HP.......................................................6 Ibf.ft / 10 Nm
ANTI-FREEZE PROTECTION
Type designation ...............................................................................Art. No 1286
Type ........................................................................................................Rubber cap
CYKLON
1.0:E46
