CYKLON
1.0:E53
Assembly:
Install the ejector sleeve (13) on the
valve housing (10). Press the sleeve into
the low pressure valve so the slits of
the sleeve are exceedingly small.
Lubricate:
Grease:
Oil:
1. Install the o-ring (6) on the valve seat
(5). Make sure that the sealing
surface is not damaged.
2. Lubricate the ball joint. Tilt the
position head according to the
figure to ensure that it rotates and
articulates smoothly.
3. Remove the rubber plate (7) with an
awl and make sure the sealings
surface on the valve is clean. Install
the new rubber plate.
4. Put the spring (9) on the valve
piston (8). Lubricate the spring
5. Install the valve piston/spring in the
valve housing with the flat part of
the valve piston upwards.
Sealing surfaces
