POSEIDON Jetstream Service Manual

Poseidon Cyklon 5000
BREATHING REGULATOR Art. No 3950
Primary pressure ................................................................................Max. 4350 PSI / 300 bar
Secondary pressure ..........................................................................Max. 174 PSI / 12 bar
Air flow ..................................................................................................Approx. 1050 l/min
Inhalation resistance at 115 l/min...............................................Max. 40 mm of water
Exhalation resistance .......................................................................Max. 20 mm of water
The above data apply when measuring at atmospheric pressure
FIRST STAGE VALVE Art. No 3720, 3720 10
Description...........................................................................................Diaphgram-actuated balanced with shear
venturi boost. Release pressure approx.
217-247 PSI / 1,5-1,7 MPa / 15-17 bar
Connecting threads for primary pressure................................G 5/8’’-max 4350 PSI / 30 MPa / 300 bar
accord. SS 2600/K and DIN 477/5 or
yoke connection accord. SS 2603 and
ANSI/CGA V1: 1987
Outlet connections:
One outlet marked R for second stage (max. airflow) UNF 3/8’’ -secondary pressure
Three outlets marked LP for Cyklon octopus,
drysuits, stadjacket............................................................................UNF 3/8’’ -secondary pressure
Two outlet marked HP for pressure gauge..............................UNF 7/16’’ -primary pressure
SECOND STAGE VALVE Art. No 1133, 3536
Description...........................................................................................Downstream-type, diaphragm actuated.
Integral safety opens with approximately
203 PSI/14 bar. Purge button for clearing.
REGULATOR HOSE Art. No 2946
Length....................................................................................................28 inch / 70 cm
TIGHTENING TORQUE
Primary connection, valve cover..................................................22 Ibf. ft / 30 Nm / 3,0 kpm
Connections marked R-LP-HP.......................................................6 Ibf.ft / 8 Nm, / 0,8 kpm
ANTI-FREEZE PROTECTION
Type designation ...............................................................................Art. No 1286
Type ........................................................................................................Rubber cap
CYKLON
1.0:E47
