0xA4 =0x80+0x24= slave is busy, EEPROM delay.
0xA5 =0x80+0x25= administrator restricted
0xA6 =0x80+0x26= set value is beyond limit.
0xA7 =0x80+0x27= CRC checksum error
0xA8 =0x80+0x28= frame format error
I-4-4. Register Address:
The register address includes two bytes, data setting is constituted by a two-byte.
Function code
Register Address high byte
Register Address low byte
0x03read
inverter
multiple
function.code
parameter
Parameter group
Parameter serial number
F
0x00
0~63
A
0x01
0~63
o
0x02
0~71
H
0x03
0~55
U
0x04
0~15
P
0x05
0~15
E
0x06
0~23
C
0x07
0~47
b
0x08
0~23
y
NOTE 1
0x09
0~23
S
0x0B
0~15
0x03.read
inverter status
Status
Status number
R
0x10
0x00
Running status NOTE 2
0x01
Reserved status 1
0x02
Reserved status 2
0x03
Reserved status 3
0x03read
inverter.fault
history record
Fault record
Fault status history record content
Fault history record1
Fault history record2
Fault history record3
Fault history record4
Fault history record5
0x20
0x21
0x22
0x23
0x24
0x00
Fault type NOTE 4
0x01
Set frequency
0x02
Actual frequency
0x03
Actual current
0x04
DC voltage
0x05
Running status NOTE 5
0x06
Running time
0x07
IGBT temperature
0x06.write
Register Address high byte
Register Address low byte
