Powtran PI8600 Series User Manual

Section V Parameter Function Table
96
Section V
When automatic regulation, motor should be in stop status
b12
Vector control initial
inspection R1
Not inspection R1
0
-
0
N
Inspection R1
1
b13
Motor 2 rated frequency
0.00~Max frequency
Hz
50.00
Y
b14
Motor 2 rated current
y09*(50%~100%)
A
★
Y
b15
Motor 2 rated voltage
100~1140
V
★
Y
b16
Motor 2 pole pairs
1~8
-
2
Y
b17
Motor 2 rated speed
500~5000
rpm
1480
Y
b18
Motor 2 N load current
0.0~b14
A
★
Y
b19
Motor 2 stator resistance
0.000~30.000
ohm
★
Y
b20
Motor 2 rotator
0.000~30.000
ohm
★
Y
b21
Motor 2 stator inductance
0.0~3200.0
mH
★
Y
b22
Motor 2 mutual inductance
0.0~3200.0
mH
★
Y
The 2nd group motor parameters can be set by system. The definition is same with group 1.
5-12 System Parameter:y00-y17(0x0900-0x0911)
Code
Description / LCD
Setting Range
Unit
Factory
Setting
Change
Limited
y00
Reset system parameter
No action
0
-
0
N
Reset system parameter
with keyboard storage1
1
Reset system parameter
with keyboard storage 2
2
Reset system parameter
with keyboard storage 3
3
Reset system parameter
with keyboard storage 4
4
Reset system parameter
with factory set value
5
0 : No action
1 : Reset system parameter with keyboard storage 1
2 : Reset system parameter with keyboard storage 2
3 : Reset system parameter with keyboard storage 3
4 : Reset system parameter with keyboard storage 4
5 : Reset system parameter with factory set value
When this parameter set valid, all the function parameter reset to factory setting. The
parameters without factory setting will save the previous setting value.
y01
Parameter upload to
keyboard
No action
0
-
0
N
Reset system parameter
with keyboard memory
area1
1
