Appendix III
133
Appendix III
PGND
Encoder
Encoder PG pulses range 300~9999
Maximum pulses frequency receiver 1MHz，when PG pulses=2500，maximum
speed=400Hz
III-3. Terminal connection instruction:
PI8600
Inverter
MCCB
Motor
3~
M
W(T3)
V(T2)
U(T1)R(L1)
S(L2)
T(L3)
T
S
R
Earthing
（Motor）
Earthing
（Power）
P18000
PG
V+
V-
A+
A-
B+
B-
PG
Earthing
Bout
Aout
B-
B+
A-
A+
PGND
V+
Bout
Aout
