b00~b04 are the motor‟s nameplate parameters which touch the precision.Set the parameters
according to the motor‟s nameplate.
b00 ~ b04 motor nameplate in parameters, it is necessary to re-calculate motor parameters
by using
b11.Excellent vector control performance requires exact motor parameters. Exact parameters
are base on the correct setting of motor‟s rated parameters.
To assure the control performance, please match the right motor as per the inverter‟s standard,
Motor rated currents limited between 30%~120% of inverter rated current.The rated current
can be set, but can‟t be more than the rated current of the inverter. The parameter
Confirms the OL protection capability of the motor and energy-saving running.
To prevent self-cooled motor form overheat when running in a low speed, and the motor
capacity change when motor character change little, the user can correct the parameter to protect
the motor.
The number of motor pole pairs, such as the four pole motor, the number of pole pairs is set
to 2
b05~b09 can by input by motor actual parameters value, also can define motor parameter by
b11 parameter measure function.and save automatically. If know the correct motor parameter,
can input by hand
When b11 is 1, 2, 3, the system calculates and measuresautomatically.
b05~b09 is the motor‟s basic electric parameters, these parameters is essential to achieve
vector control calculation.
The system can select any group motor parameters.
Motor parameter measurements modify and save to corresponding motor parameter area
automatically.
