132
Appendix III
Appendix III PG Card Instruction
III-1. Use range
Type
Encoder output method
1
+5V LINE DRIVER output
2
OPEN COLLECTOR output
3
Push-pull output type (complementary)
4
Voltage output type VOLTAGE
III-2. Terminal function instruction
terminal
Terminal function
A+ A- , B+ B-
PG signal input
Encoder output method:
1 : +5V LINE DRIVER output
JP1/JP2 jump to LD
connect method: A+->A+ , B+->B+
A- ->A-, B- ->B-
R16/R17/R18/R19 disconnect.
2 : OPEN COLLECTOR output
JP1/JP2 jump tp OC
Connect method: A ->A+ , B ->B+
R2/R4/R10/R11/R13/R15 disconect
3 : Push-pull output type (complementary)
JP1/JP2 jump tp OC
Connect method: A ->A+ , B ->B+
R2/R4/R10/R11/R13/R15 disconnect
4 : VOLTAGE output
JP1/JP2 jump to OC
Connect method: A ->A+ , B ->B+
R2/R4/R10/R11/R13/R15 disconnect
The adjustment of resistance associated with the
output voltage
V+ =5V, R16/R17/R28/R29200Ω
V+ =12VR16/R17/R28/R29=1KΩ
V+ =24VR16/R17/R28/R292KΩ
V+encoder powerthrough JP3 to select
Aout,Bout
PG signal output
Voltage output, voltage level determined by the
encoder power supply
V+
Encoder power, through JP3 to select
