Powtran PI8600 Series User Manual

128
第
十
章
Appendix II
Appendix II Instruction of the Proportional
Linkage Function
II-1. Proportional linkage function:
The proportion interaction host computer:
Communication address = 128,
Communications port A is the communication port of host computer.
Communication port B can be used as the keyboard interface, or a PC host computer interface.
There is only one host inverter in one proportional linkage.
The host inverter control the running state, the slave inverter follow the host‟s running state.
The proportion interaction slave computer:
Communication Address = 1 ~ 127,
Both communication port A and communication port B can be the communication port of
slave inverter.
In the slave inverter follow the host running and it can realize forced stopping by terminal or
keyboard if need.
For this function, the host computer should be set with the following parameters:
A28
Local communication address
128
For this function, the slave computer should be set with the following parameters:
F01
Keyboard set the frequency /
Rs485
Command from proportion linkage Host
F02
Frequency main set mode
Keyboard setting frequency or
RS485
0
AI1 the external analog setting
8000
1
AI2 the external analog setting
2
AI3 the external analog setting
3
Keyboard potentiometer setting
4
Multi-segment digital voltage set
5
Digital Pulse Setting
6
F03
Auxiliary setting mode of
frequency set
Keyboard setting frequency or
RS485
0
AI1 the external analog setting
8000
1
AI2 the external analog setting
2
AI3 the external analog setting
3
Keyboard potentiometer setting
4
Multi-segment digital voltage
setting
5
Digital Pulse Set
6
