Powtran PI8600 Series User Manual

Appendix I
127
Appendix I
Register content byte number=2 bytes * register number
Slave response
Slave address
Function code
Register address
Register number
CRC checksum
0x08
0x10
0x0001
0x0002
0x1091
0x01＝read multiple switch status
Host command read inverter whether arrive lower frequency, or arrive upper frequency
Slave address
Function code
Starter to end address
Switch number
CRC checksum
0x08
0x01
0x0006
0x0002
0x5D53
Slave response inverter not arrive lower frequency nor upper frequency
Slave address
Function code
Read byte number
Switch state
CRC checksum
0x08
0x01
0x01
0x40
0x53E4
Host command read inverter fault
Slave address
Function code
Starter to end address
Switch number
CRC checksum
0x08
0x01
0x0300
0x0020
0x3D0F
Salve response inverter low voltage (E.LU switch address 0x0305)
Slave address
Function code
Read byte number
Switch state
CRC checksum
0x08
0x01
0x04
0x20,0x00,0x00,0x00
0x6911
Note：return byte ：4 bytes；
Return date in order：bit7-bit0, bit15-bit8, bit23-bit16, bit31-bit24
0x05＝write single switch status
Host command control inverter running
Slave address
Function code
Output address
Output value
CRC checksum
0x08
0x05
0x0000
0xFF00
0x8CA3
Slave response
Slave address
Function code
Output address
Output value
CRC checksum
0x08
0x05
0x0000
0xFF00
0x8CA3
Host command control inverter stop
Slave address
Function code
Output address
Output value
CRC checksum
0x08
0x05
0x0000
0x0000
0xCD53
Slave response
Slave address
Function code
Output address
Output value
CRC checksum
0x08
0x05
0x0000
0x0000
0xCD53
Note: set switch to 1,output value is 0xFF00;set switch to 0,output value is 0x0000.
