Powtran PI8600 Series User Manual

Section V Parameter Function Table
79
Section V
U06
V/F setting frequency4
U04~U08
Hz
20.00
N
User-defined the fourth frequency value of V / F curve, corresponding to V4.
U07
V/F setting voltage 4
U05~U09
%
40
N
User-defined the fourth voltage percentage of V / F curve, on the base of rated output voltage
100% of frequency converter, corresponding to F4.
U08
V/F setting frequency5
U06~U10
Hz
25.00
N
User-defined the fifth frequency value of V / F curve, corresponding to V5.
U09
V/F setting voltage 5
U07~U11
%
50
N
User-defined the fifth voltage percentage of V / F curve, on the base of rated output voltage
100% of frequency converter, corresponding to F5.
U10
V/F setting frequency6
U08~U12
Hz
30.00
N
User-defined the sixth frequency value of V / F curve, corresponding to V6.
U11
V/F setting voltage 6
U09~U13
%
60
N
User-defined the sixth voltage percentage of V / F curve, on the base of rated output voltage
100% of frequency converter, corresponding to F6.
U12
V/F setting frequency7
U10~U14
Hz
35.00
N
User-defined the seventh frequency value of V / F curve, corresponding to V7.
U13
V/F setting voltage 7
U11~U15
%
70
N
User-defined the seventh voltage percentage of V/F curve, on the base of rated output voltage
100% of frequency converter, corresponding to F7.
U14
V/F setting frequency8
U12~Max frequency
Hz
40.00
N
User-defined the eighth frequency value of V / F curve, corresponding to V8.
U15
V/F setting voltage 8
U13~100
%
80
N
User-defined the eighth voltage percentage of V / F curve, on the base of rated output voltage
100% of frequency converter, corresponding to F8.
5-8 PID Parameter:P00-P12(0x0500-0x050C)
Code
Description / LCD
Setting Range
Unit
Factory
Setting
Change
Limited
P00
PID configuration
1 bit
Unidirectional regulation
0
-
0000
N
Bidirectional regulation
1
10 bit
Negative effect
0
Positive effect
1
100 bit
PID fault, No action
0
Warning & continuous
running
1
Warning & decelerating
stop
2
Warning & free stop
3
