Powtran PI8600 Series User Manual

20
第
十
章
Section V
Section V Parameter Function Table
Notice: ★mean that the factory setting value of the parameter is according to the power and
model.The exact value is referred to the Parameter Function Table.Change limited mean that whether
it can be modified while running.
Slant font
8000
means PI8600 do not have such function.
5-1 Menu Group
Code
Description / LCD
Function Discription
Group
ID
Refer
to page
S
Monitor function group
Monitor frequency, current and other 16
monitor objects
0B
20
F
Basic function group
Frequency setting, control mode,acceleration
time and deceleration time
00
21
A
User function group
Monitor, protection, communication setting
01
38
o
IO function group
Analog, digital input, output function
02
50
H
Multi-speed PLC group
Multi-speed running, PLCrunning
03
70
U
V/F parameter group
User defined V/Fcurve
04
78
P
PID function group
Internal PID parameter setting
05
79
E
Extend function froup
Constant pressure water supply and other
functions setting
06
82
C
Speed ring function group
Current ring, speed running, PG parameter
07
88
b
Motor parameter group
Motor parameter setting
08
94
y
System function group
Parameter reset, fault query, product
information, parameter protection
09
96
5-2 Monitor Function:S00-S15(0x0B00-0x0B0F)
Code
Description / LCD
Setting Range
Unit
Factory
Setting
Change
Limited
S00
Setting frequency
Current inverter real setting
frequency
Hz
-
N
S01
Real frequency
Current inverter real output
frequency
Hz
-
N
S02
Motor real current
Valid value of motor actual current
A
-
N
S03
Percentage of motor
current
The percentage of actual motor
current and rated current
%
-
N
S04
DC bus voltage
Detection value of DC bus voltage
V
-
N
S05
The output voltage
The real output voltage
V
-
N
