Powtran PI8600 Series User Manual

Section V Parameter Function Table
95
Section V
measurement
Calculate by label data
1
Inverter static
measurement
2
Inverter rotation
measurement
3
Set whether the measurement of electrical parameters in order to b10 motors choose motor 1
as an example.
0 : No measurement
1 : Calculate by label data
According to the motor nameplate parameters b00 ~ b04 , automatic calculation b05 ~ b09
and other electrical parameters,the advantage does not require power-on selftuning,suitable
for general- purpose Y series of four pole motor, the other type motor can be adjusted based
on this parameter.
2 : Inverter static measurement
If the motor parameters can not be measured without load,you can choose static frequency
converter measurement. Make sure that motor in a static status ,after static measurement, it
can be manually adjusted some parameters, optimal control.
The b11 is set to 2, the inverter automatically start parameter determination.
Keyboard figures area show "-RUN": waiting to run the command, start the measurement.
Keyboard figures area show "CAL1", inverter without output.
Keyboard figures area show "CAL2", inverter with output, static state.
Keyboard figures area show "-END": measuring ends.
Keyboard figures area show "E. CAL": the measurement process errors.
Process can be measured through the STOP key to stop.
3 : Inverter rotation measurement
Motor can be measured without load, can choose the rotation measurement. Measurements
started, make sure the motor is static.Static measurement converter, the output DC voltage,
pay attention to safety.
The b11 is set to 3, the inverter automatically start parameter determination.
Keyboard figures show that the regional show "-RUN": waiting to run the command, start
the measurement.
Keyboard figures area show "CAL1", "CAL3": N output inverter.
Keyboard figures area show "CAL2", inverter with output, under static state.
Keyboard figures area show "CAL4", inverter with output, the motor forward in high-speed.
Keyboard figures area show "-END": measuring the end.
Keyboard figures area show "E. CAL": the measurement process errors.
Process can be measured through the STOP key to stop.
Set this parameter,the motor parameters will be determined dynamically.Be sure the motor
is without load (N-load operation). Before setting,be sure to run well prepared,the motor will
run in high speed during the measurement
Measurement is completed, b11 return to 0. The measured parameters will select parameters
on the base of b10 motor parameters which is automatically saved to the b05 ~ b09 or b18 ~
b22.
Note: Before auto-measure the motor parameter, must input motor rated parameter b00~b04
or b13~17 correctly
Please regulate accelerating and deceleration time or torque increasing parameter, if there is
over -current or over voltage faults while auto- measurement.
