Powtran PI8600 Series User Manual

Appendix I
120
Appendix I
3
DI4 input
0
Invalid
1
Valid
4
DI5 input
0
Invalid
1
Valid
5
DI6 input
0
Invalid
1
Valid
6
DI7 input
0
Invalid
1
Valid
7
DI8 input
0
Invalid
1
Valid
8
AI1 input
0
Invalid
1
Valid
9
AI2 input
0
Invalid
1
Valid
10
AI3 input
0
Invalid
1
Valid
Output.terminal
function
0x02
0
O1 input
0
Invalid
1
Valid
1
O2 input
0
Invalid
1
Valid
2
O3 input
0
Invalid
1
Valid
3
O4 input
0
Invalid
1
Valid
Fault type
0x03
0
E.OCP
System is disturbed or
impacted by instant over
current,over current sig-
nal from current inspec-
ted circuit or drive circuit
1
Reserved
2
E.OC3
Inverter output current
exceeded 3times the
motor rated current
3
Reserved
4
E.OU
Over voltage
5
E.LU
Under voltage
