Powtran PI8600 Series User Manual

Appendix II
130
Appendix II
6: The slave actual frequency = F01 + slave potentiometer adjusting + A40
The proportional linkage host settings:
F02
Frequency main set mothod
AI2 external analog setting
A28
Communication address
Host 128
A29
Baud rate
3: 9600bps
A30
Communication format
0
o36
DI1 input terminal function select selection
1:forward running
o37
DI2 input terminal function select
2:reverse running
比例联动从机设置：
F02
Frequency main set
keyboard set the frequency
or Rs485
0
F03
Auxiliary setting mode of frequency set
AI2 external analog setting
1
F04
relationship between main and auxiliary
frequencies
main+Auxiliary
2
F05
Running control mode
Proportional linkage control
4
A28
Communication address
1~127
A29
Baud rate
Same as host inverter
A30
Communication format
Same as host inverter
o36
DI1 input terminal function select
39:Free stopping
o37
DI2 input terminal function select
40:Up command
o38
DI3 input terminal function select
41:Down command
A43
Multi-function key MF1
8:MF key is appointed to be Up
command
A44
Multi-function key MF2
9:MFkey is appointed to be
Down command
