Powtran PI8600 Series User Manual

Section II Installtion & Standby Circuit
6
Section II
DI6 can as digital pulse input.
PLC
PLC Control Terminal
PLC Control DI5~DI6 Drive model.
Drain Drive : PLC connect 24VDC or
external power .
Source Drive: PLC connect COM.
Assistant Power
24V
Assistant Power
The biggest output 24V/200mA, Can
not connect COM with GND in any
situation.
COM
Common terminal
Output signal
SPA/COM
Output signal 1
Open Collector signal when the output
action(24VDC/50mA)common terminal
COM , the output function can set by
o21, o22.
SPA, SPB provide hi-speed pulse output
function.
After setting functions by o61~o64,
Frequency inverter will take effect
again.
SPB/COM
Output signal 2
TA1/TB1/
TC1
Output signal 3
TA1-TC1open, TB1-TC1close, the
output function can set by o23.
Analog input
signal
+10V，
GND
Analog power
+10V/50mA.
AI2
Multifunction Analog
input signal 2
JP6cut: 0~10V.
JP6 connect: 0~20mA can be regulated
o02/o03 can set input voltage/ current
arrange.
o08/o09 Set the input signal
corresponding to set value.
AI3
Multifunction Analog
input signal 3
JP7cut: 0~10V.
JP7connect: 0~20mA can be regulated.
o04/o05can set input voltage/ current
arrange.
o10/o11 Set the input signal
corresponding to set value.
DA1
Multifunction Analog
output signal 1
JP1 1-2: 0~+20mA .
JP1 2-3: 0~+10VDC.
o15 set analog output analog functions.
o17/o18 set the output signal arrange.
DA2
Multifunction Analog
output signal 2
JP2 1-2: 0~+20mA.
JP2 2-3: 0~+10VDC.
o16 set analog output analog functions.
o19/o20 set the output signal arrange.
