Chapter 3 Hardware Configuration
BE-0986 SERIES USER MANUAL
Page: 3-19
3.4.17 SLIDE SWITCH FOR LVDS RESOLUTION SELECTION
Jumper Name: SW1
Description: Slide Switch for LVDS Resolution/Channel/Color Bit Selection
SELECTION
SW1
PIN
SETTING
800 x 600
1CH/18bit
(Default Setting)
1
4
OFF
ON
1
ON
2
ON
3
ON
4
ON
1024 x 768
1CH/18bit
1
4
OFF
ON
1
OFF
2
ON
3
ON
4
ON
1024 x 768
1CH/24bit
1
4
OFF
ON
1
ON
2
OFF
3
ON
4
ON
1280 x 768
1CH/18bit
1
4
OFF
ON
1
OFF
2
OFF
3
ON
4
ON
1280 x 800
1CH/18bit
1
4
OFF
ON
1
ON
2
ON
3
OFF
4
ON
